尾门杆

GAS SPRING  T8510

Fitting Position both sides
Housing Length （mm） 325
Length （mm） 583.5
Mounting points diameter left （mm） 10
Mounting points diameter right （mm） 10
Housing Diameter （mm） 18
Piston Rod Diameter （mm） 8
Extention Force （N） 420
Stroke （mm） 240.5
Specification 1PC/BOX
Weight(g) G/PC
box
cart Add to Cart
Get Quote
Compatible Vehicles
O.E.M.
COMPETITOR NUMBER
FORD
FORD > FOCUS Estate
FOCUS II TURNIER Estate DA_, FFS, DS G6DE, G6DF 2.0 (98kw/133hp) 2004-2008
View All
FOCUS II TURNIER Estate DA_, FFS, DS HWDA, HWDB, SHDA, SHDB, SHDC 1.6 (74kw/100hp) 2004-2011
View All
FOCUS II TURNIER Estate DA_, FFS, DS G8DC, MTDA 1.6 (74kw/100hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS G8DA, G8DB, G8DD, G8DE, G8DF 1.6 (80kw/109hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS G6DA, G6DB, G6DD, G6DG 2.0 (100kw/136hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS GPDA, GPDB, GPDC, HHDA, HHDB 1.6 (66kw/90hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS KKDA 1.8 (85kw/115hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS HXDA, HXDB, SIDA 1.6 (85kw/115hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS AODA, AODB, AODE, SYDA 2.0 (107kw/145hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS ASDA, ASDB 1.4 (59kw/80hp) 2004-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS Q7DA, QQDA, QQDB 1.8 (92kw/125hp) 2006-2012
View All
FOCUS II TURNIER Estate DA_, FFS, DS IXDA 2.0 (81kw/110hp) 2008-2011
View All
FOCUS II TURNIER Estate DA_, FFS, DS SYDA 2.0 (107kw/145hp) 2008-2011
View All
FORD > FOCUS Estate Van
FOCUS II Estate Van - HHDA 1.6 (66kw/90hp) 2005-2011
View All
FOCUS II Estate Van - IXDA 2.0 (81kw/110hp) 2009-2011
View All
FORD > FOCUS Hatchback
FOCUS II Hatchback DA_, HCP, DP HYDA 2.5 (166kw/225hp) 2005-2012
View All
FOCUS II Hatchback DA_, HCP, DP JZDA 2.5 (224kw/305hp) 2009-2011
View All
1349309 1684275
T8510
The manufacturer reserves the right to change the product specifications,appearance, packaging, and production location without prior notice.
