刹车盘

BRAKE DISC  BD-C0046

Outer Diameter （mm） 290
Height （mm） 45.5
Brake Disc Thickness （mm） 24
Centering Diameter （mm） 85
Num. of holes 5
Min. thickness （mm） None
Brake Disc Type Vented
Specification 2 PCS/BOX
Weight(g) 13520 G/2 PCS
BOX
cart Add to Cart
Get Quote
Compatible Vehicles
O.E.M.
COMPETITOR NUMBER
GREAT WALL
HAVAL
ISUZU
OPEL
GREAT WALL > FENGJUN Pickup
FENGJUN 3 Pickup - GW28TC2 2.8 (70kw/95hp) 2006-2013
View All
FENGJUN 3 Pickup - GW28TC2 2.8 (70kw/95hp) 2006-2013
View All
FENGJUN 3 Pickup - 4G69 2.4 (100kw/136hp) 2007-2013
View All
FENGJUN 3 Pickup - 4G69-S4N 2.4 (100kw/136hp) 2008-2013
View All
FENGJUN 5 Pickup - GW28TC2 2.8 (70kw/95hp) 2009-2015
View All
FENGJUN 5 Pickup - GW28TC2 2.8 (70kw/95hp) 2009-2015
View All
FENGJUN 5 Pickup - GW25TCI 2.5 (80kw/109hp) 2011-
View All
FENGJUN 5 Pickup - GW25TCI 2.5 (80kw/109hp) 2011-
View All
FENGJUN 5 Pickup - 4G69-S4N 2.4 (93kw/126hp) 2013-
View All
FENGJUN 5 Pickup - 4G69-S4N 2.4 (93kw/126hp) 2014-
View All
FENGJUN 5 Pickup - 4G69-S4N 2.4 (90kw/122hp) 2016-
View All
FENGJUN 5 Pickup - 4G69-S4N 2.4 (90kw/122hp) 2016-
View All
GREAT WALL > SAILING Pickup
SAILING Pickup - CA4D32 3.2 (76kw/103hp) 2007-2008
View All
SAILING Pickup - 491Q-E 2.2 (78kw/106hp) 2008-2010
View All
SAILING Pickup - 491Q-E 2.2 (78kw/106hp) 2009-
View All
SAILING Pickup - GW2.8TDI, GW2.8TDI-2 2.8 (72kw/98hp) 2009-2010
View All
GREAT WALL > SOCOOL Pickup
SOCOOL Pickup - GW491Q-E 2.2 (78kw/105hp) 2004-
View All
HAVAL > H5 SUV
H5 SUV - 4G63-S4T 2.0 (140kw/190hp) 2013-
View All
H5 SUV - GW4D20B 2.0 (100kw/136hp) 2013-2017
View All
H5 SUV - GW4D20B 2.0 (100kw/136hp) 2013-2017
View All
H5 SUV - 4G63-S4M 2.0 (90kw/122hp) 2013-2017
View All
ISUZU > TFR/TFS Pickup
TFR/TFS Pickup TFS54H 4JA1 2.5 (57kw/77hp) 1991-2002
View All
TFR/TFS Pickup TFR 6VE1 3.5 (158kw/215hp) 1995-2002
View All
ISUZU > TROOPER Closed Off-Road Vehicle
TROOPER II Closed Off-Road Vehicle UB 4ZE1 2.6 (85kw/116hp) 1991-1996
View All
TROOPER II Closed Off-Road Vehicle UB 6VD1 (SOHC) 3.2 (130kw/177hp) 1991-1998
View All
TROOPER II Closed Off-Road Vehicle UB 4JG2 T 3.1 (84kw/114hp) 1991-1998
View All
TROOPER III Closed Off-Road Vehicle - 4JX1 3.0 (117kw/159hp) 1998-2004
View All
TROOPER III Closed Off-Road Vehicle UBS25 6VD1 (DOHC) 3.2 (151kw/205hp) 1998-2004
View All
TROOPER III Closed Off-Road Vehicle - 4JX1 3.0 (117kw/160hp) 2000-2002
View All
TROOPER III Closed Off-Road Vehicle - 6VE1 3.5 (158kw/215hp) 2000-2004
View All
ISUZU > TROOPER Open Off-Road Vehicle
TROOPER II Open Off-Road Vehicle UB 6VD1 (SOHC) 3.2 (130kw/177hp) 1991-1998
View All
TROOPER III Open Off-Road Vehicle - 6VE1 3.5 (158kw/215hp) 2000-2004
View All
OPEL > FRONTERA Open Off-Road Vehicle
FRONTERA A SPORT Open Off-Road Vehicle 52SUD2, 55SUD2 C 20 NE, X 20 SE 2.0 (85kw/115hp) 1992-1998
View All
FRONTERA A SPORT Open Off-Road Vehicle 5BSUD2 28 TDI (4JB1-T), 28TD 2.8 (83kw/113hp) 1995-1996
View All
OPEL > FRONTERA Closed Off-Road Vehicle
FRONTERA A Closed Off-Road Vehicle 54MWL4 X 22 XE 2.2 (100kw/136hp) 1995-1998
View All
FRONTERA A Closed Off-Road Vehicle 5BMWL4, 5BSUD2 28 TDI (4JB1-T), 28TD 2.8 (83kw/113hp) 1995-1998
View All
FRONTERA A Closed Off-Road Vehicle U92 25TD 2.5 (85kw/115hp) 1996-1998
View All
FRONTERA B Closed Off-Road Vehicle 6B_ZC, 6B_VF, 6B_66, 6B_76 X 22 DTH, Y 22 DTH 2.2 (85kw/116hp) 1998-2003
View All
FRONTERA B Closed Off-Road Vehicle 6B_ZC, 6B_VF, 6B_66, 6B_76 X 22 SE, Y 22 SE 2.2 (100kw/136hp) 1998-2004
View All
OPEL > MONTEREY Closed Off-Road Vehicle
MONTEREY A Closed Off-Road Vehicle UBS25D, UBS25G 6VD1 (SOHC) 3.2 (130kw/177hp) 1991-1994
View All
MONTEREY A Closed Off-Road Vehicle UBS69D, UBS69G 4 JG2TC 3.1 (84kw/114hp) 1991-1998
View All
MONTEREY B Closed Off-Road Vehicle UBS26D, UBS26G 6 VE1 3.5 (158kw/215hp) 1998-1999
View All
MONTEREY B Closed Off-Road Vehicle UBS73D, UBS73G 4 JX1 3.0 (117kw/159hp) 1998-1999
View All
3501011B00
BD-C0046
The manufacturer reserves the right to change the product specifications,appearance, packaging, and production location without prior notice.
