刹车盘

BRAKE DISC  BD-1561

Outer Diameter （mm） 342.8
Height （mm） 83.1
Brake Disc Thickness （mm） 295
Centering Diameter （mm） 106.1
Num. of holes 6+6+2
Min. thickness （mm） None
Brake Disc Type Vented
Specification 1 PC/BOX
Weight(g) G/PC
BOX
cart Add to Cart
Get Quote
Compatible Vehicles
O.E.M.
COMPETITOR NUMBER
TOYOTA
VW
TOYOTA > 4 RUNNER SUV
4 RUNNER II SUV VZN130_, VZN130G, VZN130R 3VZ-E 3.0 (105kw/143hp) 1990-1995
View All
4 RUNNER II SUV KZN130_, KZN130G, KZN130W 1KZ-T 3.0 (92kw/125hp) 1993-1996
View All
TOYOTA > HIACE Van
HIACE III Van _H5_, _H6_, _H7_, _H8_, _H9_ 3Y 2.0 (65kw/88hp) 1982-1989
View All
HIACE IV Van RCH103_, RCH113_, RCH103R, RCH113R 2RZ-E 2.4 (88kw/120hp) 1989-1995
View All
HIACE IV Van LH108, LH118 2L 2.4 (55kw/75hp) 1989-1999
View All
TOYOTA > HIACE Bus
HIACE III Bus _H5_, _H6_, _H7_, _H8_, _H9_ 2L 2.4 (55kw/75hp) 1984-1989
View All
HIACE III Bus LH56, LH66 2L 2.4 (54kw/73hp) 1987-1989
View All
HIACE IV Bus _H1_ 2L 2.4 (55kw/75hp) 1987-1995
View All
HIACE IV Bus _H1_ 2RZ-E 2.4 (88kw/120hp) 1989-1995
View All
TOYOTA > HILUX Pickup
HILUX V Pickup LN85_, LN110, LN90 2L 2.4 (61kw/83hp) 1988-1997
View All
HILUX V Pickup RN106_, RN110_ 22RE 2.4 (84kw/114hp) 1989-1997
View All
HILUX VI Pickup _N1_ 2L-T 2.4 (66kw/90hp) 1998-2002
View All
HILUX VI Pickup KDN165, KDN190 2KD-FTV 2.5 (75kw/102hp) 2001-2005
View All
TOYOTA > LAND CRUISER Closed Off-Road Vehicle
LAND CRUISER Closed Off-Road Vehicle LJ70 2L-T 2.4 (66kw/90hp) 1990-1993
View All
LAND CRUISER Closed Off-Road Vehicle KZJ70_, KZJ73_, KZJ77_, KZJ78, KZJ71 1KZ-T, 1KZ-TE 3.0 (92kw/125hp) 1993-1996
View All
VW > TARO Pickup
TARO Pickup - 4Y 2.2 (69kw/94hp) 1989-1994
View All
TARO Pickup - 2Y 1.8 (61kw/83hp) 1989-1994
View All
TARO Pickup - 2L 2.4 (61kw/83hp) 1989-1997
View All
TARO Pickup - 2L 2.4 (58kw/79hp) 1994-1997
View All
42431-60120
Owner
Number
NIBK
DN1214
BD-1561
The manufacturer reserves the right to change the product specifications,appearance, packaging, and production location without prior notice.
